Technical data
Supply | 24 Vac/dc, < 1 VA |
Range | -50…50, -50…150, 0…50, 0…100 °C |
Accuracy | ±0,5 °C (0 °C) |
Sensor | Pt1000 EN 60751/B |
Output | 0…10 Vdc, 2 mA, temperature/controller |
IP protection class | IP54, cable or probe downwards |
Cable gland | M16 |
Mounting | with flange |
Materials | PBT, PC, PA, stainless steel |
Mounting depth | adjustable < 200 mm, other mounting depths also available |
